Advanced 5-Axis CNC Plasma Beveling System
The PCL 5-Axis CNC Plasma Beveling Machine is a high-performance industrial solution engineered for shipyards, pressure vessel manufacturers, and heavy steel fabricators. Unlike standard flat-plate cutters, this system utilizes a sophisticated 5-axis linkage head (X, Y, Z, A, B axes). This allows for complex 3D contour beveling in a single pass, completely eliminating the need for secondary manual beveling processes and significantly reducing welding preparation time.
Key Technical Features
V, X, Y, K Type Beveling
Supports full spatial linkage for V, X, Y, K, and other complex bevel types. The A/B axis swing range reaches ±45° (optional ±60°), meeting strict international welding standards.
Smart Initial Height Sensing (IHC)
Equipped with high-sensitivity Arc Voltage Height Control (AVHC) to monitor plate flatness in real-time. This ensures the torch maintains the optimal focal distance during beveling to guarantee edge quality.
The PCL Advantage
- ✔
Welding Readiness: Delivers clean, precise weld-ready edges directly from the machine, significantly lowering labor costs and production lead times. - ✔
Heavy-Duty Gantry Design: The frame undergoes secondary tempering and stress relief to ensure dynamic stability and high-speed positioning accuracy for decades. - ✔
Multi-Source Compatibility: Fully compatible with world-leading plasma sources including Hypertherm, Kjellberg, and high-quality LGK units for fine-hole and high-definition cutting.
| Technical Parameter | Details |
|---|---|
| Drive Mechanism | High-Torque AC Servo Drive Linkage |
| Bevel Angle Capability | A-axis: ±45° / B-axis: ±45° (Simultaneous) |
| Effective Working Area | 3000mm x 12000mm (Fully Customizable) |
| Cutting Thickness | Plasma: 1-30mm / Flame: 6-150mm |
| CNC Control Logic | Industrial Grade 5-Axis Motion Controller |
