Cantilever Welding Robot solution

Cantilever Welding Robot is a specialized automated welding system designed primarily for large-scale workpieces and structural steel components. Unlike standard industrial robots, the cantilever design features a horizontal arm extended from a vertical column, allowing the welding head to reach over large structures such as H-beams (HEB), boxes, and heavy plates.

Key Features and Advantages

• Large Working Envelope: The “overhanging” arm design provides a significant reach, making it ideal for long and wide workpieces that would be difficult to fit inside a traditional robotic cell.

• Space Efficiency: Since the robot is mounted on a single side (the cantilever column), it leaves the other side of the workspace open, allowing for easier loading and unloading of heavy materials via overhead cranes.

• High Versatility: These systems are often mounted on floor rails (linear tracks), enabling the robot to travel long distances—such as 12 meters or more—to perform continuous or intermittent welds along structural beams.

• Integration with Sensing Technology: Modern cantilever robots are frequently equipped with laser seam tracking and arc sensors to compensate for minor misalignments or thermal deformation during the welding process.

Common Applications

Cantilever welding robots are the workhorses of the heavy industry sector, specifically in:

1. Structural Steelwork: Welding of H-beams, I-beams, and complex truss sections.

2. Shipbuilding: Joining large hull plates and stiffeners.

3. Construction Machinery: Fabricating chassis for excavators, cranes, and trucks.

4. Bridge Construction: Welding of large-scale girders and support structures.

Technical Parameters

Model GR-WL500 7 axis welding robot Arm span: 2000mm(customizable) Camera:3D,With high and low viewing distance functions Walking rail:Standard length: 9M & 12M (can be customized) Welding function:Support dual-machine collaborative welding function Repeatable positioning accuracy: ±0.05mm Voltage: 3 phase 380V Industrial robot control system Support TCP and camera hand-eye automatic calibration function Control servo:EtherCAT bus servo Operating mode:Teaching, online, remote Programmatically:Online teaching, process programming Welding wire diameter: 0.8mm,1.0mm,1.2mm,1.6 mm Gas flow: 15-20L/min

Detailed Photos

1). The system can meet the normal work of two shifts per day (8 hours per shift), and can maintain stable accuracy

2)After repeated demonstration and simulation design of the design drawings of the workstation, the strength of each component is reliable, the assembly and maintenance are convenient, and the appearance is beautiful under the premise of ensuring the function.

3)All the purchased parts of the workstation equipment are provided by well-known manufacturers in the industry (see configuration list for details), and the quality of all the workpiece is strictly checked, the strength is up to standard, the performance is superior and the movement is smooth.

4)The measurement unit of the parts and instruments of the workstation equipment and all the drawing data adopts the National standard (GB) standard; All instruments, components and components shall be designed, manufactured and used in accordance with ISO and IEC standards or other equivalent standards.

5)The workstation parts are made of high-quality materials, and the selected mechanical and electrical components are high-quality, mature and reliable series products.

6)The end of the robot has an anti-collision sensor, which can be stopped in time to protect the collision, and the automatic cleaning gun cutting system can be configured according to the demand.

7)Workstation parametric modeling, 3D digital-analog drive, intelligent planning of welding path, laser vision sensor photo correction path, beyond the limit deviation range alarm, matching parameters and process library automatic creation of welding procedures and other intelligent welding functions.
